TWR-Jaguar XJR-9LM walkaround

Front view of the engine cover. Of note are the various openings in it. Inside the largest openings ('follow the yellow line'), a small metal duct was fitted that appeared to connect to the square opening in the heat cover over the exhaust. Also note the metal pins that connect to the monocoque.

Photo by Michel Jamin
